Tunnel length: 1.65 kilometers
Geological conditions: high water pressure, deep overburden, complex soft and hard rock formations
Shield type: mud-water shield 6.7 m
Product type: Shield tail 2200 barrels
Geological conditions: high water pressure, deep overburden, complex soft and hard rock formations
Shield type: mud-water shield 6.7 m
Product type: Shield tail 2200 barrels
Xiangya Road Crossing River Project, China Railway Construction 14th Bureau
Tunnel length: 1.425 km / 1.429 km
Geological conditions: high water pressure, deep overburden, complex soft and hard rock formations
Shield type: mud-water shield 15.01 m
Product type: Shield tail 2200 barrels
Geological conditions: high water pressure, deep overburden, complex soft and hard rock formations
Shield type: mud-water shield 15.01 m
Product type: Shield tail 2200 barrels
Shantou Suaiwan Tunnel, China Railway Tunnel Bureau
Tunnel length: 3.048 kilometers
Geological conditions: soft soil, sandy soil, granite boulders, composite strata
Shield type: mud-water shield 14.96 m
Product type: Shield tail 1500 barrels
Geological conditions: soft soil, sandy soil, granite boulders, composite strata
Shield type: mud-water shield 14.96 m
Product type: Shield tail 1500 barrels
Natural gas pipeline project, China Railway Tunnel Bureau
Tunnel length: 10.226 kilometers in one direction
Geological conditions: mudstone, silty sandstone
Shield type: mud-water shield 7.95 m
Product type: Shield tail 2200 barrels
Geological conditions: mudstone, silty sandstone
Shield type: mud-water shield 7.95 m
Product type: Shield tail 2200 barrels
Tunnel length: 4.97 / 3.66 / 5.712 / 9.215 kilometers
Geological conditions: silty clay, fine sand, gravel
Shield type: 9m / 14.2 m
Product type: black oil/shield tail (110/1300 barrels)
Geological conditions: silty clay, fine sand, gravel
Shield type: 9m / 14.2 m
Product type: black oil/shield tail (110/1300 barrels)
Tunnel length: 3.05 km / 2.97 km
Geological conditions: hard rock, soft rock, quartz sandstone
Shield type: 16.03m / 14.93 m
Product Type: Black Oil / Shield Tail (220 / 1900 barrels)
Geological conditions: hard rock, soft rock, quartz sandstone
Shield type: 16.03m / 14.93 m
Product Type: Black Oil / Shield Tail (220 / 1900 barrels)
Yichun Phosphate Mine Water Blocking Project
Water inflow occurred at the TBM working face on March 21, 2022, with a volume of approximately 200 cubic meters/hour. Since the TBM cutter head and the tunnel face are closely connected, it is difficult to accurately determine the specific location of the water. There is no drilling operation space in front of the cutter head, so it must be retreated to a position 9 meters away from the working surface for drilling and grouting to block water. At the same time, in order to prevent the materials injected during the grouting process from influxing into the tunnel, silicate foam materials need to be injected between the TBM shield and the surrounding rock to protect the shield. A total of 1.5 tons of foam material was injected to completely protect the shield. Inject 4 tons of water blocking materials. Completely block the working surface water.
Liangshan Tunnel Filling and Reinforcement Project
In the on-site situation, the water spray on the working surface was large and scattered (as shown in the figure), and the water inflow in the entire tunnel reached about 2,000 cubic meters per day. The lithology of the surrounding rock is sandy mudstone and is severely weathered. After being soaked in water, it becomes looser and its strength is greatly reduced.
Nano silicon body water blocking project in a mine tunnel
When the auxiliary inclined shaft was constructed to the 440m-550m section, the water spray on the tunnel roof reached more than 38m³/h, and the water inflow after grouting was 0.5m³/h.
